Capturing an Intel Processor Trace Data Stream by a PCIe-Attached FPGA Monitoring

Datum

21.09.2017

Zeit

09:00 - 10:00

Sprecher

Albert Schulz

Zugehörigkeit

Institut für Technische Informatik, Professur Prozessordesign

Sprache

en

Hauptthema

Informatik

Andere Themen

Informatik

Beschreibung

The development and operation of safety-critical processing systems requires broad capabilities with respect to system observability and online monitoring. This demand has been addressed by microprocessor manufacturers through chip area dedicated to a growing number of execution statistics and tracing units. The extremely valuable detail of the insight provided by instruction or even data traces, however, also implies a challenge in mastering the vast amounts of trace data produced already over small time frames. In consequence, an effective combination of online verification, event triggering and trace filtering is needed for satisfying long-running monitoring requirements. In this diploma thesis, the infrastructure to activate and capture the trace of an Intel x86 processor by a PCIe-attached FPGA monitoring engine has been developed.A decoder implementation is presented, that allows for the first layer of packet extraction, i.e. identification of packet types and their payload.Based on various measurements and statistics, the quality and completeness of the trace data has been examined. In addition, an outlook for the further processing is given.Many practical use cases require the reconstruction of the program flow.For that reason, expectations and requirements for such a processing stage are derived from the decoder implementation and the trace analysis. Diese Veranstaltung wird unterstützt von Professur Prozessordesign.
